1. 2 Tbps Switching Capacity and 1488 Mpps Forwarding Rate.
2. 1+1 Hot-Swap Power Supplies and 4 Hot-Swap Fans.
3. Data Center Features incl. VXLAN, MLAG, etc.
4. Support ROCE-based RDMA Networks.
5. Support L3+ features incl. static routing, RIP, OSPF, BGP, etc.
C6700-24Y4C 24-Port 25G/100G Switch, 24x 25G SFP28, 4x 100G QSFP28, MLAG, VXLAN
6COM C6700-24Y4C 24-port 25Gb switch with 40G/100G QSFP28 uplinks features high performance, high-density, and full layer 3 data center features (VXLAN, MLAG, etc). It is best for L3+ aggregation to next-generation enterprises, data centers, Metro, and HCI (Hyper-Converged Infrastructure) networks.
| Ports | 24x 25G SFP28 | 4x 100G QSFP28 | Packet Buffer | 36 MB |
| Switching Capacity | 2 Tbps | Forwarding Rate | 1488 Mpps |
| MAC Address | 98304 | ARP Table | 16384 |
| VLAN IDs | 4K | Jumbo Frame | 9600 bytes |
| IPv4 Routes | 60K | IPv6 Routes | 4096 |
| FLASH | 8 GB | RAM | 2 GB |
| Latency | 700ns | Airflow | Front-to-Back |
| Power Supply | 2 (1+1 redundant) | Fan Number | 4 hot-pluggable fans |
| Max. Power Consumption | 160 W | MTBF | 198,000 hours |
| Operating Temperature | 0°~45°C (32°~113°F) | Weight | 9.2kg |
| Dimensions (H×W×D) | 4.36 x 44.0 x 48.0 cm (1.73 x 17.5 x 18.9 in.) | Warranty | 5 Years |
Rate Support Functions Applications
With 24x 25G Ports Supporting MLAG, VXLA Suitable for HCI, Metro
and 4x 100G Uplinks NVGER and GENEVE tunnel technology Data Center and Enterprise applications
The C6700 series data center switch is an L3+ switch that supports full Layer 3 functionality (static routing, RIP, OSPF, BGP, etc.) and advanced data center features such as high-reliability MLAG and tunneling technologies like VXLAN, NVGRE, and GENEVE for virtual networks. The C6700 series switches are suitable for Ethernet aggregation platforms in HCI (Hyper-Converged Infrastructure), metropolitan area networks, data centers, and enterprise applications.
All the module models listed below have been tested and verified to operate on the device.
| Transceivers | BIDI Transceivers | DACs & AOCs | |
|---|---|---|---|
| 25-Gigabit | SFP-25G-SR | SFP-25GBX-U-10 | 6C-SFP28-CA-P |
| SFP-25G-LR | SFP-25GBX-D-10 | 6C-SFP28-AOC | |
| 6C-SFP28-LH | SFP28-BIDI-LH-27 | / | |
| 6C-SFP28-ER | SFP28-BIDI-LH-33 | / | |
| SFP-25G-ER | / | / | |
| 100-Gigabit | QSFP-100G-SR4-S | 6C-QSFP28-BX20-U | 6C-Q28-2Q28-CA-P |
| QSFP-100G-LR4-S | 6C-QSFP28-BX20-D | 6C-Q28-4S28-CA | |
| 6C-QSFP28-PSM4 | 6C-QSFP28-BX40-U | QSFP28-100G-DAC | |
| QSFP-100G-ZR4-S | 6C-QSFP28-BX40-D | 6C-Q28-4S28-AOC | |
| QSFP-100G-ER4L-S | / | QSFP28-100G-AOC |
CompatibilityTest for C6700-24Y4C
Reliable manufacturer and seller of optical network products
What Can 6COM Bring to You
Industry-leading after-sales processing capabilities
6COM has been in this business for 12 years. We have rich experience in dealing with various problems, you can rest assured to buy products at 6com without worrying about after-sales problems.
The most competitive purchase cost in the industry
6COM's excellent production management model makes the module price at the bottom of the industry in the market. You can get the best quality products at budget.
Various swtiches for compatibility testing
Since 2010, 6com has purchased more than 140+ network switches, covering popular equipment of 10G/40G/100G brands.
Rigorous performance testing
Eye diagram test, waveform test, bit error test and other tests ensure the stability of the module
